Model |
S01US32A |
S01US40A |
S01US48A |
||
|
Current |
32A |
40A |
48A |
||
|
Power |
7 KW |
9.6 KW |
11.5 KW |
||
|
Voltage |
AC 110-240V |
AC 110-240V |
AC 110-240V |
||
|
Cable Specification |
3*10AWG+1*18AWG TPE OD:16.5mm |
2*9AWG+10AWG+18AWG TPE OD:16.5mm |
2*9AWG+10AWG+18AWG TPE OD:16.5mm |
||
|
Charging connector |
Type 1 Plug + 5M cable |
||||
|
Authentication |
Auto charging /card swipe / APP |
||||
|
User Interface |
LED indicator+LCD display(4.3 inch) |
||||
|
Standard |
SAEJ1772 |
UL2594 |
UL62 |
|
|
|
Product Dimensions |
Control Box: 250*250*60mm |
||||
|
Ingress Protection |
Charging plug: IP65 Control box: IP65 |
||||
|
Environmental Temperature |
-35°C to 55°C |
||||
|
Ground Fault Detection |
30mA for AC faults (Type A ) or 30mA for AC and 6mA for DC faults (Type A + 6) |
||||
|
Case Material |
Aluminum + Theroplastic (flame retardant grade UL94-0) |
||||
|
Product Performance |
Over voltage protection. Under volage protection. Over load protection. Leakage Protection. Ground protection. Over temperature protection (85°C). Lightning protection. Short circuit protection. Flame retardant. |
||||
